RP7008 Tower parking system
Tower parking system is a modern type becuase of it's effectiveness in saving space. It can accomodate 17 levels with 2 car spaces on each and occupy only 3 car spaces of usual conventional parking area.
Detail
Video
Features:
- It is controlled with PLC , accompanied with touch screen . Process of parking has never been easier.
- This kind of parking suits residential areas, it is good looking as much as apartment or office buildings
- Driven with a number of motors and a system of steel cables.
- Multiple security detection devices are configured in order to ensure the safe and reliable operation.
- Anti-fall device
- Alarm device for preventing people or vehicle from entering when the machinery is running.
- Alarm device for prevention of exceeding height and length of vehicles
- Low-voltage, lack-phase, over-current and overload protection device
- Power-off self-locking protection device
- Emergency stop button device.
|
Specification |
|
|
Control mode |
PLC ,automated |
|
Load capacity |
≤2500KG |
|
Vehicle size (mm) |
5300×1900×2050 |
|
Lifting speed |
90 m/min |
|
Motor power |
30 kW |
|
Shuttle speed |
60 m/min |
|
Shuttle power |
2× 2.2 kW |
|
Robotic trolley speed |
60m/min |
|
Robotic trolley power |
2×0.75 kW |
|
Driving mode |
Chain |
|
Motor voltage |
380V/50HZ |
